Dimensions and Measurements
Flow Rate (GPM) | 1.8 |
Handshower Flow Rate | 1.5 |
Hose Length | 59 in. |
Shower Arm Reach | 12 in. |
Showerhead Flow Rate (GPM) | 1.8 |
Showerhead Height | 2.25 in. |
Showerhead Width | 7.6875 in. |
Valve Trim Height | 9.6875 in. |
Valve Trim Width | 3.9375 in. |
Water Connection | 1/2" |
Included Components
Bodysprays Included | No |
Diverter Included | Yes |
Handles Included | Yes |
Handshower Included | Yes |
Hose Included | Yes |
Includes Exposed Pipe Riser | No |
Installation Hardware Included | Yes |
Integrated Diverter | Yes |
Shower Arm Included | Yes |
Shower Head Included | Yes |
Slide Bar Included | No |
Tub Spout Included | No |
Valve Included | No |
Valve Trim Included | Yes |
Volume Control | Yes |
Wall Supply Included | Yes |
Characteristics and Features
Control Type | Manual |
Diverter Location | Valve Trim |
Exposed Installation | No |
Faucet Type | Shower System |
Handle Material | Metal |
Handle Style | Lever |
Handshower | Single Function |
Installation Type | Wall Mounted |
Material | Metal |
Number Of Handles | 2 |
Showerhead | Single Function |
Showerhead Material | Brass |
Showerhead Shape | Square |
Spray Nozzles | 144 |
Spray Pattern | Rain |
Spray Settings | 1 |
Theme | Transitional |
Valve Trim Material | Brass |
Valve Type | Thermostatic |
Water Connection Type | NPT |
Water Efficient | Yes |
The Graff Solar GM2.022WD-LM31E0-T is a complete wall-mounted thermostatic shower system with an 8″ single-function showerhead, 12″ shower arm, coordinating hand shower, wall bracket, and 59″ hose. The system includes a 3/4″ thermostatic rough valve and trim for maintaining a consistent water temperature, along with a 3/4″ two-way diverter valve that switches water flow between the showerhead and hand shower. Two lever-style handles provide separate temperature and function control, while no-clog, easy-clean spray nozzles simplify showerhead maintenance. The system is ADA compliant.
Features
Showerhead
- 8" square single-function showerhead
- 144 no-clog, easy-clean spray nozzles
- Maximum showerhead flow rate of 1.8 GPM
- Includes 12" wall-mounted shower arm
- Square wall flange
Hand Shower
- Coordinating hand shower
- Wall-mounted hand-shower bracket
- 59" flexible shower hose
- Maximum hand-shower flow rate of 1.5 GPM
Thermostatic Control
- 3/4" concealed thermostatic rough valve and trim
- Maintains a consistent selected water temperature
- Built-in service stops
- Universal 3/4" inlets
- Front-accessible internal components
- Thermostatic valve flow rate of approximately 12.9 GPM at 60 PSI
Diverter Control
- 3/4" two-way diverter and volume-control valve
- Switches water between the showerhead and hand shower
- Operates one shower function at a time
- Integrated shutoff function
- Pass-through and stacking-port capability
- Universal 3/4" threaded connections
Design and Compliance
- Solar Collection design
- Two metal lever handles
- Decorative control trim
- Wall-mounted installation
- Rough-in valves included
- ADA compliant
- CALGreen compliant depending on selected functions
Item Attributes
| Brand Code: | GRAFF |
|---|---|
| Part Number: | GM2.022WD-LM31E0-PC-T |
| GTIN14: | 843444192593 |
| Category Code: | Showerheads & Accessories |
| Sub Category Code: | Showerheads & Accessories |
GRAFF M Series Thermostatic Shower System Polished Chrome 1.8 Gpm GM2.022WD-LM31E0-PC-T
- SKUI-0000097401
- Model #GM2.022WD-LM31E0-PC-T
| Condition | New |
|---|---|
| Type |  |
| Grade | A |
| Product Source |  |
| Additional Info | Damaged in box |
7 DAY RETURNS ON ALL PRODUCTS
| Brand | GRAFF |
|---|---|
| Category | Showerheads & Accessories |
| Model Number | GM2.022WD-LM31E0-PC-T |
| UPC/GTIN | 843444192593 |
| Capacity | 1.8000 |
| Color | Polished Chrome |
| Depth | 2 1/4 |
| Width | 7 11/16 |
| Height | 2 1/4 |
