| Specification | Value |
|---|---|
| Style | Standard Hood |
| Venting Type | Ducted |
| Blower Included | Yes |
| Blower Type | Internal |
| Width | 46 3/8 Inch |
| Depth | 22 1/2 Inch |
| Height | 16 3/8 Inch |
| WiFi | No |
| CFM | 1,200 CFM |
| Noise Level | 3.5 Sones |
| Duct Size | 10 Inch |
| Number of Fan Speeds | 3 |
| Lights | LED |
| Delay Shut-Off | No |
| Brand | Zephyr |
| Series | Pro Collection |
| Model | AK9846BS |
| Type | Insert Liner |
| Color | Stainless Steel |
| Mounting Type | Under Cabinet |
| Bluetooth | No |
| Filter Type | Baffle |
| Lighting Levels | 2 |
| Amps | 10 |
| Voltage | 120 Volts |
| UPC | 646328010644 |
The Zephyr Spruce AK9846BS outdoor hood insert delivers up to 1,200 CFM of ventilation for covered outdoor cooking areas. Its one-piece liner is constructed from corrosion-resistant 304-grade stainless steel and can be incorporated into a custom wall or island hood enclosure. Three-speed metallic knob controls provide straightforward operation, while directional LumiLight LED lighting offers two brightness levels to illuminate the cooking surface. Professional baffle filters and a removable stainless steel grease tray capture cooking residue and simplify cleanup, making this insert well suited for outdoor grilling spaces.
Features
Ventilation
- Included internal blower delivers 450–1,200 CFM
- Three fan speeds
- Vertical exhaust through a 10" round duct
- Designed for covered outdoor patios and lanais
Lighting & Controls
- Four directional LumiLight LED lights
- Two lighting levels
- Front-mounted metallic knob controls
Construction & Cleaning
- Corrosion-resistant 304-grade stainless steel
- Three professional baffle filters
- Dishwasher-safe filters using low heat
- Removable stainless steel grease tray
- One-piece liner for custom wall or island installations
- UL listed
Item Attributes
| Brand Code: | ZEPHYR |
|---|---|
| Part Number: | AK9846BS |
| GTIN14: | 646328010644 |
| Category Code: | Kitchen Appliances |
| Sub Category Code: | Kitchen Appliances / Range Hoods |
ZEPHYR 48" Outdoor Hood Insert Stainless Steel AK9846BS
- SKU-0000045188
- Model #AK9846BS
| Condition | New |
|---|---|
| Type |  |
| Grade | A |
| Product Source |  |
| Additional Info | New In Box | Clearance |
| Available Quantity | 1 |
