Dimensions and Measurements
Capacity (Gallons) | 72 |
Depth | 18.9375 in. |
Height | 20.25 in. |
Length | 72 in. |
Nominal Length | 72 in. |
Nominal Width | 36 in. |
Overflow Height | 15.1875 in. |
Product Weight | 120 lbs. |
Water Depth | 15 in. |
Width | 36 in. |
Included Components
Arm Rests Included | Yes |
Blower | Yes |
Drain Assembly Included | No |
Faucet Included | No |
Handshower Included | No |
Heater Included | Yes |
Light Included | No |
Tile Flange | Yes |
Characteristics and Features
Accepts Deck Mount Faucet | No |
Apron Front | Yes |
Control Type | Electronic |
Drain Placement | Right |
Installation Type | Three Wall Alcove |
Jet Type | Air |
Material | Acrylic |
Number Of Bathers | 1 |
Number of Jets | 120 |
Overflow | Yes |
Pump Placement | Left |
Theme | Transitional |
Tub Shape | Rectangular |
Manufacturer Technology
Chromatherapy | No |
Electrical and Operational Information
Amperage | 15 |
Frequency | 60 Hertz |
Speeds | 18 |
Voltage | 120 |
Wattage | 600 |
Warranty and Product Information
ADA | Yes |
ANSI Certification | A117.1 |
ASME Code | A112.19.7 |
Certifications | ANSI, ASME, CSA |
Collection | Archer |
Country Of Origin | USA |
CSA Code | C22.2, B45.5, B45.10 |
Made in America | Yes |
Manufacturer Warranty | Limited Lifetime |
Kohler® Bathtub, Archer® Collection, Theme/Style: Transitional, Bath Therapy Type: Airjet, BubbleMassage™, Rectangular Shape, 72 in Length, 36 in Width, 20-1/4 in Height, 18-15/16 in Tub Depth, 72 gal Water Capacity, Right Drain Location, 3-1/2 in Drain Height, 1-1/2 in Drain, 51-3/8 x 21 in Bathing Well, Electronic Keypad Control, Yes Overflow Hole, 15-3/16 in Overflow Height, 64-1/2 x 30-1/2 in Opening, 120 Jets, Alcove Mounting, Acrylic, White, Domestic/Import: Domestic
Features
- 120 airjets release thousands of heated bubbles that surround and support the body in a warm massage
- Automatic and manual purge cycles remove residual water from air channels after use
- Variable-speed blower lets you adjust massage intensity to 18 levels
- Comfort Depth® design offers a convenient 19" step-over height while retaining the same depth as a standard 21" bath
- Integral lumbar support
- Slotted overflow allows for deep soaking
- Integral apron
- Integral flange helps prevent water from seeping behind wall and simplifies alcove installation
- Textured bottom surface
- Coordinates with other products in the Archer collection
- Built-in 600W BubbleMassage™ heater warms humidified air before it enters the bath
Item Attributes
| Brand Code: | KOHLER |
|---|---|
| Part Number: | 1124-GHRA-0 |
| GTIN14: | 885612783202 |
| Category Code: | Bathtubs |
| Sub Category Code: | Bathtubs |
KOHLER Archer 72" Three Wall Alcove Acrylic Air Tub With Right Drain And Overflow Comfort Depth Design 1124-GHRA-0
- SKUI-0000095624
- Model #1124-GHRA-0
| Condition | New |
|---|---|
| Type |  |
| Grade | A |
| Product Source |  |
| Additional Info | New In Box |
| Available Quantity | 1 |
